CONFIGURATION
2-way Reversed Array
DRIVERS
1 Tweeter 32 mm SILVERSOFT™
dome NeFeB motor
1 Woofer 170 mm ROHACELL®
Full-Apex™ Poly-Ring NeFeB motor
SENSITIVITY
90 dB SPL normalized to 1 m/2.83 Vrms/
de-correlated L/R pink noise in
ITU-R BS 1116-1 compliant listening room
LOW FREQUENCY CUT OFF
55 Hz @ -3 dB referred to C4 WETS
XOVER FREQUENCY
1180 Hz
ALIGNMENT
LKR4 Derived (Δf=45°)
RATED IMPEDANCE
Modulus 4 Ω (min 3.0) Argument ±36°
LOW FREQUENCY LOAD
Back-Firing Vented
VENT GEOMETRY
Half-Exponential Hourglass Type
CABINET
Solid walnut and hdf
SPEAKER ORIENTATION
Speakers should be titled inward facing the listener
LISTENING DISTANCE
Optimum speaker-listener distance > 3.0m
LISTSENING LAYOUT
A carpeted floor in front of the speakers is recommended
SIDE AND BACK WALLS
Should be at least 1m away from the speaker front baffle
SIZE
445 x 235 x 340 mm (H x W x D)
WEIGHT
14 Kg
SUGGESTED AMPLIFIERS
Rated for 120 W / 4 Ω Average Power
